HOW TO USE:
To open the diffuser device, hold the base in one hand and the top in the other hand and twist anticlockwise.
Remove the battery pack provided from the base.
Remove the lid from the top half of the device and insert the 2x AA batteries. Ensure the Positive (+) and Negative (-) terminals are aligned and replace the lid.
Ensure the diffuser is switched to the OFF position, (light will flash red once when device is switched to OFF mode is selected). Insert the refill into the base, align the small line marking (top edge of the device base) with the back of the can's spray nozzle. Place the top half of the device on the base ensuring the spray nozzle is facing through opening in the top half. Twist the top half clockwise lining up the triangle marking with the mark on the base.
Select the desired level of protection (see CHOOSING THE BEST SETTING table). The flashing green light indicates the device will spray after a delay of 15 seconds. If there is no spray after 15 seconds, switch off the device and check steps 3 and 4 have been performed correctly before repeating step 5.
When the aerosol refill is almost empty the red light will flash and the device will soon stop spraying. Turn the device off. Remove the refill and replace with a new refill using the above steps. Remove the lid and adjust device to desired setting and press the reset button.
Choosing the best setting:
Mortein NaturGard Multi-Insect Automatic Spray Indoor & Outdoor gives you the control you need to enjoy protection from pests every day. Choose the time setting that meets your needs according to the table below.
#The choice of setting may be affected by air changes, location layout, temperature, humidity & the time of day. The Hi Indoor setting releases product every 13 minutes, the Lo Indoor setting every 17 minutes. The Hi Outdoor setting releases product every 20 seconds, the Lo Outdoor setting every 40 seconds.
Choosing where to locate the diffuser:
Recommended rooms indoors include lounge & family rooms, away from immediate food preparation, children activity & pet sleeping areas.
In an outdoor setting, the device is only to be used in well ventilated, sheltered outdoor areas only when mosquitoes and flies are prevalent.
Mount the diffuser at least 2m above the floor and not closer than 30cm from the ceiling, roof or any outdoor or indoor structure facing an open area (refer to wall mounting guide).
If it fails to spray, please read the TROUBLE-SHOOTING directions
NOT TO BE USED FOR ANY PURPOSE, OR IN ANY MANNER, CONTRARY TO THIS LABEL UNLESS AUTHORISED.
WALL MOUNTING GUIDE
HANG THE DIFFUSER UNIT AT LEAST 2m HIGH ON THE WALL AND NOT CLOSER THAN 30cm FROM THE CEILING OR ROOF OF ANY OUTDOOR STRUCTURE. For Indoor use, recommended for use only in well ventilated rooms 15m2 and above.
Do not install, use or store closer than 5m away from naked flame, heat or any incandescent material, for example near stoves, heaters, refrigerators, barbecues, outdoor heaters, open fireplaces and outdoor refrigerators.
When determining where to hang the diffuser unit, ensure that you use an appropriate hook for the wall surface selected.
The diffuser unit and full aerosol refill weigh approximately 550g. Do not open or close the diffuser when the unit is hanging on the wall as it may loosen the hook causing the diffuser to fall.
IMPORTANT NOTES
1. Ensure you direct the diffuser away from your face at all times.
2. In case of absence from your home for a week or longer, turn off the diffuser,
placing the switch in the OFF position.
3. When refill can is empty, replace with Mortein Multi-Insect Automatic Spray refill cans only.
If there is no green light, check the batteries are inserted correctly. If it fails to spray,
please read the TROUBLE-SHOOTING directions. Batteries need to be replaced when the green light stops flashing or when the diffuser stops spraying.
USE MORTEIN AUTOMATIC SPRAY REFILL CANS ONLY.
4. Do not leave the diffuser unit exposed to direct sunlight or rain for extended periods or when not in use. The diffuser unit is not waterproof. Do not leave unprotected outside.
TROUBLE-SHOOTING
• Turn off the device by moving the switch to the OFF position.
• Remove the refill can.
• Check the batteries are inserted correctly aligning the positive (+) and negative (-) terminals.
• Insert the refill can and switch on the diffuser.
• If the diffuser still does not spray after checking the above, the batteries may require replacing.
• The diffuser unit may be cleaned with a dry disposable cloth.
Please keep for future reference when refilling.
PRECAUTIONS: KEEP OUT OF REACH OF CHILDREN. EXTREMELY FLAMMABLE.
Do not direct onto humans, pets, exposed food, water, food preparation areas or food utensils. Do not allow children & pets to play or eat directly under device. Do not use in outdoor areas that are completely enclosed by walls or screens, e.g. sunrooms. Do not operate near eyes or towards the face. Excessive inhalation or exposure may cause allergy in sensitive individuals. Avoid inhalation of spray mist. DO NOT STORE OR USE NEAR FIRE OR FLAME. DO NOT SMOKE DURING USE. VERY ECOTOXIC TO AQUATIC LIFE. DO NOT THROW PRODUCT INTO WATERWAYS. REMOVE FISH TANKS BEFORE USING. COVER FISH PONDS. DO NOT USE NEAR BEES. Surfaces may become slippery once sprayed. Should surfaces become slippery, clean with warm soapy water and dry thoroughly. Care should be taken not to spray delicate fabrics, furnishings or plastic surfaces such as TVs or other electronic equipment.
BEWARE: DELIBERATELY SNIFFING OR
INHALING CONCENTRATED SPRAY
CAN BE HARMFUL OR FATAL.
Do not install, use or store closer than 5m away from naked flame, heat or any incandescent material, for example near stoves, heaters, refrigerators, barbecues, outdoor heaters, open fireplaces and outdoor refrigerators.
When determining where to hang the diffuser unit, ensure that you use an appropriate hook for the wall surface selected.
The diffuser unit and full aerosol refill weigh approximately 550g. Do not open or close the diffuser when the unit is hanging on the wall as it may loosen the hook causing the diffuser to fall.
IMPORTANT NOTES
1. Ensure you direct the diffuser away from your face at all times.
2. In case of absence from your home for a week or longer, turn off the diffuser,
placing the switch in the OFF position.
3. When refill can is empty, replace with Mortein Multi-Insect Automatic Spray refill cans only.
If there is no green light, check the batteries are inserted correctly. If it fails to spray,
please read the TROUBLE-SHOOTING directions. Batteries need to be replaced when the green light stops flashing or when the diffuser stops spraying.
USE MORTEIN AUTOMATIC SPRAY REFILL CANS ONLY.
4. Do not leave the diffuser unit exposed to direct sunlight or rain for extended periods or when not in use. The diffuser unit is not waterproof. Do not leave unprotected outside.
TROUBLE-SHOOTING
• Turn off the device by moving the switch to the OFF position.
• Remove the refill can.
• Check the batteries are inserted correctly aligning the positive (+) and negative (-) terminals.
• Insert the refill can and switch on the diffuser.
• If the diffuser still does not spray after checking the above, the batteries may require replacing.
• The diffuser unit may be cleaned with a dry disposable cloth.
Please keep for future reference when refilling.
PREPARATION INSTRUCTIONS
Do not install, use or store closer than 5m away from naked flame, heat or any incandescent material, for example near stoves, heaters, refrigerators, barbecues, outdoor heaters, open fireplaces and outdoor refrigerators.
When determining where to hang the diffuser unit, ensure that you use an appropriate hook for the wall surface selected.
The diffuser unit and full aerosol refill weigh approximately 550g. Do not open or close the diffuser when the unit is hanging on the wall as it may loosen the hook causing the diffuser to fall.
IMPORTANT NOTES
1. Ensure you direct the diffuser away from your face at all times.
2. In case of absence from your home for a week or longer, turn off the diffuser,
placing the switch in the OFF position.
3. When refill can is empty, replace with Mortein Multi-Insect Automatic Spray refill cans only.
If there is no green light, check the batteries are inserted correctly. If it fails to spray,
please read the TROUBLE-SHOOTING directions. Batteries need to be replaced when the green light stops flashing or when the diffuser stops spraying.
USE MORTEIN AUTOMATIC SPRAY REFILL CANS ONLY.
4. Do not leave the diffuser unit exposed to direct sunlight or rain for extended periods or when not in use. The diffuser unit is not waterproof. Do not leave unprotected outside.
TROUBLE-SHOOTING
• Turn off the device by moving the switch to the OFF position.
• Remove the refill can.
• Check the batteries are inserted correctly aligning the positive (+) and negative (-) terminals.
• Insert the refill can and switch on the diffuser.
• If the diffuser still does not spray after checking the above, the batteries may require replacing.
• The diffuser unit may be cleaned with a dry disposable cloth.
Please keep for future reference when refilling.
SAFETY DIRECTIONS
PRECAUTIONS: KEEP OUT OF REACH OF CHILDREN. EXTREMELY FLAMMABLE.
Do not direct onto humans, pets, exposed food, water, food preparation areas or food utensils. Do not allow children & pets to play or eat directly under device. Do not use in outdoor areas that are completely enclosed by walls or screens, e.g. sunrooms. Do not operate near eyes or towards the face. Excessive inhalation or exposure may cause allergy in sensitive individuals. Avoid inhalation of spray mist. DO NOT STORE OR USE NEAR FIRE OR FLAME. DO NOT SMOKE DURING USE. VERY ECOTOXIC TO AQUATIC LIFE. DO NOT THROW PRODUCT INTO WATERWAYS. REMOVE FISH TANKS BEFORE USING. COVER FISH PONDS. DO NOT USE NEAR BEES. Surfaces may become slippery once sprayed. Should surfaces become slippery, clean with warm soapy water and dry thoroughly. Care should be taken not to spray delicate fabrics, furnishings or plastic surfaces such as TVs or other electronic equipment.
BEWARE: DELIBERATELY SNIFFING OR
INHALING CONCENTRATED SPRAY
CAN BE HARMFUL OR FATAL.
SAFETY DIRECTIONS: May irritate the eyes and skin. Avoid contact with eyes and skin.
Storage Temperature: DO NOT EXPOSE CAN TO TEMPERATURES EXCEEDING 50°C,
